JXDTRO
JX
8040
DTRO works by using advanced reverse osmosis membrane technology to separate solute from solvent through high-pressure water molecule filtration. Its unique design with small disc tubes and numerous tiny channels increases membrane area, enhances water treatment efficiency, and prevents membrane clogging.
DTRO Specifications
Model | Max. Working Pressure | Effective Membrane Area | Max. Temperature | pH | Wet Weight | Rejection rate | Flux |
JXMP9.0-R04 | 90bar | 9.405m2 | 45℃ | 3-11（Operate） 2-12(CIP) | 70kg | 99% | 250L/H |
JXHP12.0-DT-RO4 | 120bar | 100kg | 98% | 250L/H | |||
JXHP16.0-DT-RO4 | 160bar | 100kg | 98% | 250L/H |
Applications of DTRO (Disk Tube Reverse Osmosis) and STRO (Spiral Tube Reverse Osmosis) Membranes
DTRO (Disk Tube Reverse Osmosis) and STRO (Spiral Tube Reverse Osmosis) membrane technologies have a wide range of applications in various fields. Here are some of the main uses in different application areas:
DTRO (Disk Tube Reverse Osmosis)
Leachate Treatment:
DTRO technology has significant advantages in treating leachate from landfills. It can handle highly polluted, high-salinity leachate, effectively removing organic matter, heavy metals, and other contaminants.
Industrial Wastewater Treatment:
Used for treating various types of industrial wastewater, such as from chemical, pharmaceutical, and food processing industries. DTRO technology can effectively reduce the volume of wastewater and recover valuable resources.
Mining Wastewater Treatment:
Suitable for treating wastewater discharged from mines, removing heavy metals and other pollutants from the water, thereby protecting the environment and water resources.
High-Concentration Organic Wastewater Treatment:
Particularly suitable for treating high-concentration organic wastewater from pharmaceutical plants, chemical factories, and other industries, reducing pollutant discharge.
